Victron Multiplus 12V-230V 500Va Inverter/Charger (Bare Unit)

NCC Trained · Victron Dealer

Victron Multiplus 12V-230V 500Va Inverter/Charger (Bare Unit)

Victron Energy

£286.08

Warranty 5 years

Available to order

Design your full system

183 five-star Google reviews

Delivery

We're closed for a family wedding from Monday 26 to Wednesday 28 October. Orders placed during this time are processed when we reopen on Thursday 29 October.

Free UK delivery on orders over £50

  • Made in the UK · NCC & Victron trained team
  • Technical support from the people who build the systems
  • Need help? Speak with an expert

About this product

INVERTERS · 500VA · INVERTER + CHARGER
✓ Pure Sine Wave✓ 500Va✓ Built-in 20A Charger✓ PowerAssist✓ Compact
Compact inverter/charger — 500Va inverter + 20A battery charger in one unit

Delivers seamless 240V AC off-grid power and battery charging in a single three-in-one unit. Combining a 500VA pure sine wave inverter, a 20A mains charger and an automatic transfer switch eliminates separate units, cutting installation wiring complexity whilst saving valuable interior space.

The transfer switch allows you to use the same sockets in the van whether you're on grid or off-grid. This is the ideal entry-level choice if your off-grid 240V needs focus on laptops, cameras, and phone chargers alongside steady campsite battery maintenance.

  • 500Va inverter (430W continuous) + 20A battery charger in one unit
  • PowerAssist — supplements shore power with battery power for peaks
  • Pure sine wave — safe for all electronics
  • Seamless transfer between shore power and inverter (<20ms)
  • Compact — smallest in the MultiPlus range
  • G-ST18i AC connector
  • VE.Bus port for Cerbo GX integration
  • Pre-programmed for lithium batteries and fine-tuned for campervan systems before dispatch — less setup, just connect and go

⚡ Key Features

01Three-in-One

Inverter AND battery charger. Eliminates the need for a separate mains charger. Charges at 20A when connected to shore power.

02PowerAssist

If shore power is limited (e.g., 6A hookup), the MultiPlus supplements with battery power to handle peak loads. No more tripped breakers.

03Seamless Transfer

Millisecond switchover between shore power and inverter means your appliances stay running. No interruption when arriving or departing.

04System Integration

VE.Bus port connects to Cerbo GX for full system monitoring via VRM portal. Coordinate with solar and alternator charging for optimal battery management.

🔌 What Can It Run?

The MultiPlus 500Va delivers approximately 350W continuous (500Va, 1000W peak). Also charges your battery at 20A when on shore power. Here's what it can run:

✓

Phone/Tablet Charger

10-25W
Multiple devices

✓

Laptop

45-90W
Any laptop charger

✓

LED Lighting

10-50W

✓

Small Fan

30-50W

✓

TV (LED, up to 24-inch)

50-100W

✓

Electric Blanket

50-100W
Single size, short use

✗

Travel Kettle (small)

500-800W
Too much — will trip

✗

Microwave

600-1000W
Too much

✗

Hair Dryer

1200-2000W
Too much

Combined Load Examples

Phone + Laptop + LED lights + TV: ~200W — comfortable

Laptop + fan + phone: ~150W — fine

Electric blanket + phone charger: ~120W — short periods

Va (volt-amps) differs from watts due to power factor. Brief peaks above rated output are OK, but continuous load should stay within 350W.

🔧 Tech Specs

Shared
  • Model : MultiPlus 12/500/20-16
  • Part number : PMP122501100
  • Inverter Rating : 500Va
  • Continuous Output : 430W
  • Peak Power : 900W
  • Charger Output : 20A
  • Transfer Switch : 16A
  • AC Connection : G-ST18i connector
  • Output : Pure sine wave 230V 50Hz
  • Input : 12V DC (9.5-17V)
  • AC Input : 187-265VAC, 45-65Hz
  • Efficiency : ~90%
  • Zero Load : ~6W (Search: ~2W)
  • Protection : IP21
  • Dimensions : H311 x W182 x D100mm
  • Weight : 4.4kg
  • Warranty : 5 years

🔌 You Might Also Need

Inverter DC Leads + Isolator 500Va

Battery to inverter cabling with rotary isolator

Mains Hook-Up Kit

For shore power

Leisure Battery

100Ah+ recommended

Questions and answers

Can Rayne Automotive help me choose the right option?

Yes. Use the System Builder for a full specification, or book a consultation and tell us what you want to run and what is already fitted.

Do you supply trade accounts?

Yes. Van converters can apply for a Rayne Automotive trade account for kit pricing and support.

Is help available after I buy?

Yes. The Help Centre carries installation instructions, and the team supports what it sells.
