Mains Double Pole 2-way Consumer Unit

NCC Trained · Victron Dealer

Mains Double Pole 2-way Consumer Unit

Rayne Automotive

£54.99

Warranty 1 year

Available to order

Design your full system

183 five-star Google reviews

Delivery

We're closed for a family wedding from Monday 26 to Wednesday 28 October. Orders placed during this time are processed when we reopen on Thursday 29 October.

Free UK delivery on orders over £50

  • Made in the UK · NCC & Victron trained team
  • Technical support from the people who build the systems
  • Need help? Speak with an expert

About this product

Standard 2-way campervan 240V consumer unit with double-pole RCD and dual MCBs.

Protects dual 240V AC circuits in your campervan with a 40A 30mA double-pole Type A RCD main switch, a 6A MCB, and a 16A MCB. It provides independent circuit protection for your battery charger and 13A socket outlets while ensuring full BS 7671 18th Edition compliance. Double-pole isolation disconnects both live and neutral lines to safeguard against reversed polarity on European campsites. The standard choice for campervan conversions requiring reliable multi-circuit mains power safety.

🔧 Tech Specs

Shared
  • Nominal Voltage : 230V AC, 50Hz
  • Main Isolation Switch : 40A 30mA Double Pole RCD
  • Outgoing Circuit Breakers : 1x 6A Double Pole MCB + 1x 16A Double Pole MCB
  • Enclosure Material : High-impact flame-retardant thermoplastic with hinged cover
  • Standards : BS EN 61008, BS EN 60898, BS 7671
  • Dimensions : 175 x 185 x 100 mm
  • Weight : 2 kg
  • Warranty : 1 Year

🔌 You Might Also Need

Mains 240V Power Board with Charger: Pre-wired upgrade option on CNC phenolic plywood backing board.

Double Sockets (Brushed Silver / Black Nickel / C-Line): 13A interior mains socket outlets.

Questions and answers

Can Rayne Automotive help me choose the right option?

Yes. Use the System Builder for a full specification, or book a consultation and tell us what you want to run and what is already fitted.

Do you supply trade accounts?

Yes. Van converters can apply for a Rayne Automotive trade account for kit pricing and support.

Is help available after I buy?

Yes. The Help Centre carries installation instructions, and the team supports what it sells.
