Mains 240V Double Narrow RCBO Consumer Unit

NCC Trained · Victron Dealer

Mains 240V Double Narrow RCBO Consumer Unit

Rayne Automotive

£64.98

Warranty 1 year

Available to order

Design your full system

183 five-star Google reviews

Delivery

We're closed for a family wedding from Monday 26 to Wednesday 28 October. Orders placed during this time are processed when we reopen on Thursday 29 October.

Free UK delivery on orders over £50

  • Made in the UK · NCC & Victron trained team
  • Technical support from the people who build the systems
  • Need help? Speak with an expert

About this product

Space-saving 240V campervan consumer unit fitted with two compact narrow-body RCBOs.

Protects dedicated charger and socket circuits independently against earth leakage and overcurrent using single-module narrow double-pole RCBOs. It delivers full dual-circuit mains safety in a slim enclosure, saving vital cupboard space. Individual RCBO trip controls ensure an outlet fault will not shut off your battery charger. Ideal for tight conversion layouts where space is limited but maximum 240V circuit protection is essential.

🔧 Tech Specs

Shared
  • Supply Voltage : 230V AC, 50Hz
  • Protection Modules : 2x Narrow Double Pole RCBOs (10A 30mA + 16A 30mA)
  • Isolation : Independent double-pole switching on both output circuits
  • Enclosure Rating : Flame-retardant compact enclosure, IP40/IP65 rated
  • Compliance : BS 7671 18th Edition Section 721 regulations
  • Dimensions : 175 x 145 x 100 mm
  • Warranty : 1 Year

🔌 You Might Also Need

Mains Inlet Socket Flush Mount: For external campsite power connection.

13A Switched Double Sockets: Interior 240V power outlets.
