Foxygen 12V 460Ah LiFePO4 Leisure Battery

NCC Trained · Victron Dealer

Foxygen 12V 460Ah LiFePO4 Leisure Battery

Foxygen

£769.99

Currently unavailable

Design your full system

Delivery

Dispatched every Monday and Thursday with next-day delivery

  • Made in the UK · NCC & Victron trained team
  • Technical support from the people who build the systems
  • Need help? Speak with an expert

About this product

All-Electric Campervans · Expedition Vehicles · Extreme Off-Grid
✓ 460Ah LiFePO4✓ 5.88kWh Energy✓ 250A Smart BMS✓ Switchable Heating✓ 12-Year Warranty
Maximum-capacity 460Ah lithium leisure battery packing 5.88kWh usable power with 250A BMS, switchable winter heating, Bluetooth, and a 12-year warranty.

Generates 5,888Wh of usable energy to drive high-power appliances without installing multiple battery banks. This heavy-duty lithium leisure battery offers 6,000 deep cycles for gas-free cooking and long-range autonomy. An integrated BMS continuously protects cell health while delivering high discharge currents. If you are creating an all-electric camper conversion requiring high capacity in one unit, this is the ideal choice.

  • 460Ah / 5,888Wh usable LiFePO4 capacity — huge single-battery energy store
  • Replaces heavy multi-battery parallel setups with one streamlined 38.58kg unit
  • Integrated 250A Smart BMS supports continuous discharge for inverters up to 2500W
  • Switchable internal heating pads allow safe charging in sub-zero winter conditions
  • Integrated Bluetooth for real-time tracking of state of charge, voltage, and temperature
  • Long-life Grade A prismatic cells rated for 3500+ cycles at 80% Depth of Discharge
  • Market-leading 12-year manufacturer warranty

⚡ Key Features

01Massive 5.88kWh Single-Casing Capacity

Delivers true off-grid independence for all-electric campervan systems without parallel wiring complications or excessive weight.

02Smart BMS Protection

Integrated 250A Battery Management System protects against overcharging, over-discharging, short circuits, high/low temperatures, and cell imbalance.

03Winter Heating Capability

Switchable heating pads warm the internal cell pack during cold winter months, enabling seamless charging from alternator and solar inputs.

0412-Year Long-Term Guarantee

Built for decade-plus durability and backed by Foxygen's 12-year warranty for complete confidence on every journey.

🔋 Estimated Runtime

Based on the System Builder’s appliance power and daily-use settings, with a 460Ah × 12.8V = 5888Wh lithium battery. Each tile shows one load on its own, with no solar or alternator charging; no reserve or losses are deducted. Real mixed-use runtime will be shorter.

Compressor Fridge (48L)

~18.4 days

40W × 8h/day = 320Wh/day

LED Down Lights x 4

~147.2 days

8W × 5h/day = 40Wh/day

Phone/Tablet Chargers

~147.2 days

20W × 2h/day = 40Wh/day

12V TV (24 inch)

~65.4 days

30W × 3h/day = 90Wh/day

Diesel Heater

~83.6 days

8.8W × 8h/day = 70.4Wh/day

Water Pump

~392.5 days

60W × 0.25h/day = 15Wh/day

🔧 Tech Specs

Shared
  • Capacity : 460Ah (5,888Wh)
  • Nominal Voltage : 12.8V
  • Chemistry : LiFePO4 (Lithium Iron Phosphate) - Grade A Prismatic Cells
  • Weight : 38.58kg
  • Dimensions : 521mm (L) x 238mm (W) x 218mm (H)
  • Max Continuous Discharge Current : 250A
  • Cycle Life : 6,000 cycles at 80% DoD
  • BMS Features : Integrated 250A Smart BMS with Bluetooth app monitoring, switchable winter self-heating, full thermal, overcurrent, and voltage protection
  • Warranty : 12 Years
