Foxygen 12V 230Ah LiFePO4 Leisure Battery

Foxygen

£499.98

Currently unavailable

Design your full system

Delivery

Dispatched every Monday and Thursday with next-day delivery

  • Made in the UK · NCC & Victron trained team
  • Technical support from the people who build the systems
  • Need help? Speak with an expert

About this product

Campervan Electrics · Off-Grid Upgrades · Long-Life Lithium
✓ 230Ah LiFePO4✓ 250A Smart BMS✓ Switchable Heating✓ Bluetooth App✓ 12-Year Warranty
High-performance 230Ah LiFePO4 lithium leisure battery with 250A BMS, switchable heating, Bluetooth, and an industry-leading 12-year warranty.

Stores 2,944Wh of usable energy inside an IP65 waterproof casing built for harsh environment touring. This durable lithium leisure battery yields over 6,000 deep cycles and comes backed by an extensive 12-year warranty. The rugged housing protects internal components against water ingress and vibration whilst on the road. If you need long-term reliability and weather-resistant performance, this is the ideal choice for dependable off-grid power.

  • 230Ah / 2,944Wh high-capacity LiFePO4 leisure battery for off-grid campervan builds
  • Integrated 250A Smart BMS supports up to 2500W continuous inverter loads
  • Internal switchable heating pad permits safe charging in sub-zero winter conditions
  • Built-in Bluetooth connectivity for live battery monitoring via mobile app
  • Ultra-lightweight 21.28kg design — saving over 40kg compared to equivalent AGM banks
  • Rated for 3500+ cycles at 80% DoD for 10-15+ years of reliable service
  • Unrivalled 12-year manufacturer warranty

⚡ Key Features

01Industry-Leading 12-Year Warranty

Foxygen provides superior long-term protection, backing their high-grade LiFePO4 cells and Smart BMS with a 12-year guarantee.

02Integrated 250A Smart BMS

Safeguards internal cells against overcharge, over-discharge, overcurrent, short circuits, and extreme temperatures while supplying up to 250A continuous discharge.

03Switchable Internal Heating

Integrated heating elements warm internal lithium cells when cold temperatures are detected, ensuring safe winter charging from solar or alternators.

04Bluetooth App Monitoring

Track real-time state of charge, voltage, current draw, and cell temperatures on your smartphone without fitting external shunts.

🔋 Estimated Runtime

Based on the System Builder’s appliance power and daily-use settings, with a 230Ah × 12.8V = 2944Wh lithium battery. Each tile shows one load on its own, with no solar or alternator charging; no reserve or losses are deducted. Real mixed-use runtime will be shorter.

Compressor Fridge (48L)

~9.2 days

40W × 8h/day = 320Wh/day

LED Down Lights x 4

~73.6 days

8W × 5h/day = 40Wh/day

Phone/Tablet Chargers

~73.6 days

20W × 2h/day = 40Wh/day

12V TV (24 inch)

~32.7 days

30W × 3h/day = 90Wh/day

Diesel Heater

~41.8 days

8.8W × 8h/day = 70.4Wh/day

Water Pump

~196.3 days

60W × 0.25h/day = 15Wh/day

🔧 Tech Specs

Shared
  • Capacity : 230Ah (2,944Wh)
  • Nominal Voltage : 12.8V
  • Chemistry : LiFePO4 (Lithium Iron Phosphate)
  • Weight : 21.28kg
  • Dimensions : 367mm (L) x 190mm (W) x 245mm (H)
  • Max Continuous Discharge Current : 250A
  • Cycle Life : 6,000 cycles at 80% DoD
  • BMS Features : Integrated 250A Smart BMS with Bluetooth, switchable self-heating, overcharge, over-discharge, overcurrent, short circuit, and thermal cut-off protection
  • Warranty : 12 Years
