Fogstar Drift Gen2 12V 230Ah LiFePO4 Leisure Battery

NCC Trained · Victron Dealer

Fogstar Drift Gen2 12V 230Ah LiFePO4 Leisure Battery

Fogstar

£639.99

Available to order

Design your full system

Delivery

Dispatched every Monday and Thursday with next-day delivery

  • Made in the UK · NCC & Victron trained team
  • Technical support from the people who build the systems
  • Need help? Speak with an expert

About this product

Campervan Conversions · Off-Grid Touring · High-Capacity Lithium Upgrades
✓ 230Ah LiFePO4✓ 300A Smart BMS✓ Automatic Heating✓ Active Balancing✓ 10-Year Warranty
Gen2 230Ah lithium leisure battery with an uprated 300A Smart BMS, active cell balancing, heating, and Bluetooth monitoring.

Supplies 2,944Wh of fully usable power to run your off-grid 12V equipment without rapid discharge. This high-performance lithium leisure battery features active cell balancing and integrated self-heating for reliable winter charging.

Built-in Bluetooth monitoring lets you track cell voltages and state of charge directly from your smartphone. If you want hassle-free power independence for multi-day off-grid trips, this is the ideal choice for modern touring.

  • 230Ah / 2,944Wh usable LiFePO4 capacity for extended off-grid campervan power
  • Uprated 300A Smart BMS with 0.2A shunt accuracy and integrated active cell balancing
  • Automatic self-heating enables safe charging in sub-zero winter temperatures
  • Grade A EVE prismatic cells delivering 4,000 cycles at 80% Depth of Discharge
  • Built-in Bluetooth connectivity for live battery monitoring via the Fogstar Drift app
  • 300A max continuous discharge current — ideal for running up to 3000W inverters
  • Backed by a 10-year UK manufacturer warranty

⚡ Key Features

01Uprated 300A Smart BMS & Active Balancing

The Gen2 BMS allows continuous discharge up to 300A for large inverter loads, while active cell balancing maintains individual cell voltage equality for long-term cell health.

02Direct Victron plugin via can ports - this unit can be connected into the Victron Cerbo GX without any need for an external shunt making it ideal as part of a high spec system with beautiful monitoring.

03Automatic Cold-Weather Heating

Integrated heating pads automatically warm the internal cells to safe charging temperatures when cold conditions are detected, ensuring seamless year-round UK van life.

04Bluetooth App & Accurate State of Charge

Connect directly via the Fogstar Drift app to monitor exact battery percentage, cell voltages, temperature, and cycle count with high-precision shunt measurement.

0510-Year UK Warranty & Support

Engineered and backed by Fogstar in the UK with Grade A prismatic cells rated for over 4000 deep cycles.

🔋 Estimated Runtime

Based on the System Builder’s appliance power and daily-use settings, with a 230Ah × 12.8V = 2944Wh lithium battery. Each tile shows one load on its own, with no solar or alternator charging; no reserve or losses are deducted. Real mixed-use runtime will be shorter.

Compressor Fridge (48L)

~9.2 days

40W × 8h/day = 320Wh/day

LED Down Lights x 4

~73.6 days

8W × 5h/day = 40Wh/day

Phone/Tablet Chargers

~73.6 days

20W × 2h/day = 40Wh/day

12V TV (24 inch)

~32.7 days

30W × 3h/day = 90Wh/day

Diesel Heater

~41.8 days

8.8W × 8h/day = 70.4Wh/day

Water Pump

~196.3 days

60W × 0.25h/day = 15Wh/day

🔧 Tech Specs

Shared
  • Capacity : 230Ah (2,944Wh)
  • Nominal Voltage : 12.8V
  • Chemistry : LiFePO4 (Lithium Iron Phosphate) - Grade A EVE Prismatic Cells
  • Weight : 23.5kg
  • Dimensions : 383mm (L) x 193mm (W) x 250mm (H)
  • Max Continuous Discharge Current : 300A
  • Cycle Life : 4,000 cycles at 80% DoD (10-15 year lifespan)
  • BMS Features : 300A Smart BMS with 0.2A shunt accuracy, active cell balancing, automatic self-heating, overcharge, over-discharge, short circuit, overcurrent, and temperature protection
  • Warranty : 10 Years

🔌 You Might Also Need

Victron Orion XS 50A DC-DC Charger

High-efficiency alternator charger designed specifically for lithium leisure battery systems.

Victron Smart IP22 12V Battery Charger

Multi-stage mains charger with dedicated lithium charging profile.

Victron SmartShunt

Recommended when integrating your battery system into a Victron Cerbo GX monitoring network.
