Victron Orion XS 50A Isolated DC-DC Battery Charger

NCC Trained · Victron Dealer

Victron Orion XS 50A Isolated DC-DC Battery Charger

Victron Energy

£288.00

Warranty 5 years

Available to order

Design your full system

183 five-star Google reviews

Delivery

Dispatched every Monday and Thursday with next-day delivery

Free UK delivery on orders over £50

  • Made in the UK · NCC & Victron trained team
  • Technical support from the people who build the systems
  • Need help? Speak with an expert

About this product

SPLIT CHARGE · LITHIUM ONLY
✓ Bluetooth Monitoring✓ 98.5% Efficiency✓ 50A Output✓ Latest Generation✓ Smart Alternator Ready
Next-generation DC-DC charger — 50A output, ultra-compact, 98.5% efficient

Delivers a powerful 50A charge rate to your leisure battery whilst driving, getting maximum power from modern alternators. This Victron Orion XS charger operates at 98.5% efficiency to minimise heat output and protect your electrical system during heavy charging. Built-in Bluetooth provides complete control over output currents and charging profiles via your phone. If you need rapid power recovery for lithium banks without taking up unnecessary space, this is the ideal high-performance choice.

  • 50A output — the fastest practical DC-DC charging for most vans
  • Latest generation — more efficient and compact than Orion Smart
  • 98.5% charging efficiency — minimal energy wasted as heat
  • Bluetooth monitoring via VictronConnect app
  • Smart alternator compatible (Euro 6 engines)
  • Full rated output up to 40°C ambient temperature
  • 8 battery presets + fully custom settings

⚡ Key Features

01Latest Generation

The Orion XS is Victron's newest DC-DC charger. More compact, more efficient, and cooler-running than the Orion Smart. The current state of the art in alternator charging.

0298.5% Efficiency

The most efficient DC-DC charger available. Less wasted energy means cooler operation and more power delivered to your battery. Full rated output maintained even in hot engine bay conditions.

0350A

Maximum Practical — At 50A, this charger can replenish a 100Ah battery from 0% in about 1-2 hours of driving. For most vans, this is the maximum practical charging speed.

048 Battery Presets

Quick setup with presets for common battery types, or fully customise via VictronConnect. Built-in engine running detection prevents drain when the engine is off.

🔧 Tech Specs

Shared
  • Model : Orion XS 12/12-50A
  • Output Current : 50A
  • Input Voltage : 9-17V (12V systems)
  • Output Voltage : 10-17V (configurable)
  • Charge Profile : 3-stage (bulk → absorption → float)
  • Battery Compatibility : Lithium, AGM, gel, flooded (8 presets)
  • Smart Alternator : Yes
  • Bluetooth : Yes — VictronConnect app
  • Efficiency : 98.5%
  • Max Operating Temp : 40°C at full output
  • IP Rating : IP65
  • Dimensions : 140 × 108 × 70mm
  • Weight : 1.2kg
  • Warranty : 5 years (Victron)

🔌 You Might Also Need

Split Charge Cable Kit (25mm²)

Heavy-duty for 50A current

12V Fuse Box

6-way (SC7) or 12-way (SC6)

Lithium Leisure Battery

View range

Questions and answers

Can Rayne Automotive help me choose the right option?

Yes. Use the System Builder for a full specification, or book a consultation and tell us what you want to run and what is already fitted.

Do you supply trade accounts?

Yes. Van converters can apply for a Rayne Automotive trade account for kit pricing and support.

Is help available after I buy?

Yes. The Help Centre carries installation instructions, and the team supports what it sells.
