£595.94 (options vary)
Warranty 1 year
Available to order
183 five-star Google reviews
Delivery
Dispatched every Monday and Thursday with next-day delivery
Free UK delivery on orders over £50
Every option below is priced live from the shop. Choose on this page or in the panel above.
| Option | Price |
|---|---|
| 2 | £595.94 |
| 3 | £799.74 |
| 4 | £1,056.43 |
Use the sun to charge your leisure battery with the harvest of a multi-panel array — without the height, weight, or wind resistance of rigid panels. Two to four 150W semi-flexible panels mount flush to the roof, connected through a SmartSolar MPPT controller sized for the array's combined output. Panels, controller, array cabling, roof-entry hardware, and a PV isolator in one kit (excluding fixings and adhesives/sealants).
For elevating roofs, curved surfaces, and vans where aesthetics matter as much as amps, this is the way to get serious solar charging. Each panel weighs kilos, not tens of kilos — and nothing protrudes above the roofline.
The kit arrives matched: panels, controller, array cabling with series connections, and the roof-entry hardware. Design it once on the roof, wire it up, and the MPPT controller reports the total harvest live to your phone — with the last 30 days of history in the VictronConnect app.
717Wh
approx. 56Ah per day222Wh
approx. 17Ah per day1076Wh
approx. 84Ah per day333Wh
approx. 26Ah per day1434Wh
approx. 112Ah per day444Wh
approx. 35Ah per dayReal UK seasonal estimates from our power calculator's solar model — 2.39 effective sun-hours/day in summer, 0.74 in winter. Yields shown per full day.
Two, three, or four flexible panels give you 300-600W of harvesting, all sitting flush with the roofline. You get serious charging power with the silhouette of a standard van.
The MPPT controller in this kit handles the combined current of all your panels — not a single-panel controller hoping to keep up. Harvest gets converted, not clipped.
Multiple rigid panels can exceed the mechanism's weight allowance. Multiple flexible panels deliver the harvest without the mass.
Bluetooth in the controller shows total array output live. See the effect of shade, tilt, and season on your actual harvest numbers.
Store the array's harvest properly
Alternator backup charging
Track state of charge from your phone
For a fridge plus normal 12V loads, 2 panels (300W) cover summer well. Full-time off-grid with an inverter — 3 or 4. Flexible panels cost slightly more per watt than rigid, so rigid is better value if weight and height aren't concerns.
Yes — mounted flush to a dark roof, they run hotter than rigid panels on brackets. MPPT control recovers most of that loss. In very hot climates, rigid panels with airflow underneath are more efficient; in UK conditions, the difference is minor.
Yes — the panels connect in series down a single cable run to the controller, with inline fusing per string. It's all pre-matched to the controller's rating.
It's not recommended — different electrical characteristics mean the MPPT controller can't track both panels' maximum power points simultaneously. Pick one type for the whole array.
Yes. Use the System Builder for a full specification, or book a consultation and tell us what you want to run and what is already fitted.
Yes. Van converters can apply for a Rayne Automotive trade account for kit pricing and support.
Yes. The Help Centre carries installation instructions, and the team supports what it sells.
Plan the charging, storage and distribution together with the System Builder, browse the example complete systems, or book a consultation and tell us what you want to run and what is already fitted.
